Print Head:PF-03
Technology : FINE (Photolithography Inkjet Nozzle Engineering)
Print Resolution (Max.): 2400 x 1200dpi
Line Accuracy : ±0.1% or Less
Minimum line Weight: 0.02mm
Number of Nozzles Matte Black:       5,120 Nozzles
Other Colours: 2,560 Nozzles per Colour
Droplet Size:   4 Picoliter
Nozzle Pitch (Head Resolution) : 1200dpi x Two Rows
Print Head Swath : 1.07in.
Ink Tank
Ink Type Dye: Cyan (C), Magenta (M), Yellow (Y), Black (K)
Pigment: Matte Black (MBK)
Model PFI-303 / PFI-703
Ink Capacity : 330ml / 700ml
Number of Colours : 5
Ink Supply Method : Tubing system (independent ink tanks)
Nozzle Recovery System : Non-firing Nozzle Detection and Compensation
Printer Controller : L-COA Controller
Printer Memory : 384MB
Media feed : Front-loading Manual Feed, Back-loading Roll Feed
Media Width
Roll Feed, Manual Feed : 203mm - 1118mm
Media size
Cutsheet Manual feed from the front:  ISO A4, A3+, A2, A1, A0, B4, B3, B2, B1, B0, DIN C4, C3, C2, C1, C0, JIS B4, B3, B2, B1, B0 ANSI Letter (8.5" x 11"), Legal (8.5" x 14"), 11" x 17", 13" x 19", 17" x 22", 22" x 34", 28" x 40", 34" x 44", ARCH (9" x 12", 12" x 18", 18" x 24", 24" x 36", 26" x 38", 27" x 39", 30" x 42", 36" x 48"), 20" x 24", 18 x 22", 14" x 17", 12" x 16", 10" x 12", 10" x 15", 16" x 20" (US Photo size), Poster (20" x 30", 30" x 40", 42" x 60", 300 x 900mm), 13" x 22"
Roll paper Width: IS0 A3, A2, A1, A0, JIS B2, B1, B0, ARCH D (24", 30", 36"), 10", 14", 16", 17", 42", 44"
Borderless Printing Widths (Roll Media Only) : JIS B2 (515mm), JIS B0 (1030mm), A1 (594mm), A0 (841mm), 10", 14", 17", 24", 36", 42"
Media Type*1: Plain Paper, Recycled coated paper, High resolution paper, Coated paper, Heavyweight coated paper, Extra heavyweight coated paper, Premium matte paper, Matte photo paper, Glossy photo paper, Semi-glossy photo paper, Heavyweight glossy photo paper, Heavyweight semi-glossy photo paper, Glossy paper, Photo paper pro, Photo paper plus, Photo paper plus semi-glossy, Synthetic paper, Proofing paper, CAD Tracing paper, CAD Translucent matte film, POP board and others
Printable Margins
Roll Feed All Sides:    3mm or 0mm for Borderless
Manual Feed   Left, Right, Top:  3mm
Bottom: 23mm
Minimum Printable Media length : 8.0" (203mm)
Maximum Print length*2
Roll Feed : 59" (18m)
Manual Feed (Front)   5.2" (1.6m)
Media Cutter: Automatic horizontal cutting (Rotary cutter), independent unit
Media Thickness
Front-loading Manual Feed : 0.07 - 0.8mm
Roll Feed: 0.07 - 0.8mm
Media Core Sizes : Internal diameter of roll core:      2" / 3"
Maximum Roll Outer Diameter : 150mm

Software

Printing Software : imagePROGRAF Printer Driver 2008, HDI Driver for AutoCAD / AutoCAD,LT 2000 - 2008, Printer Driver Extra Kit (Free Layout, imageRUNNER Linking Function)
Utilities : Media Configuration Tool
Applications :  GARO Device Setup Utility, Poster Artist 2008 (optional)
Device Status : GARO Status Monitor, Remote UI
Printer language : GARO (Graphic Arts language with Raster Operations), HP- GL/2, HP RTL
Operating Systems      Windows 2000 / XP / Windows Vista Macintosh OS 9 / 10 (PowerPC or Intel)

Interface

Standard (Built-in): USB 2.0 Hi-Speed, 10 / 100Base-T / TX
Optional  : IEEE1394 (FireWire)
Acoustic noise
Operation : 52dB (A) or Less
Standby : 35dB (A) or Less
Acoustic Power : 6.8 Bels or Less
Power Supply : AC 100 - 240V (50 - 60Hz)
Power Consumption
Maximum : 190W or Less
Standby : (100 - 120V) 5W or Less (10W or less when IEEE1394 is mounted)
Standby : (220 - 240V)           6W or Less (11W or less when IEEE1394 is mounted)
Power Off :     1W or Less (Executive Order Compliant)
Certifications : ENERGY STAR (WW), RoHS Directive, IT ECO Declaration (Europe), WEEE, Executive Order of the President of the United States of America, China RoHS directive
Operational Environment
Temperature :  15 - 30°C
Relative Humidity : 10 - 80% (No Condensation)
Dimensions (H x W x D) : 1893 x 975 x 1144mm (with Printer Stand)
Weight (with Stand)   Approx. 141kg
Options : IEEE1394 Expansion Board (EB-05)
Roll Holder Set (RH2 -44)
Media Take-up Unit (TU-06)
Portable Media Basket (BU-03)
PosterArtist 2008
User Replaceable Items : Print Head (PF-03)
Ink Tanks (PFI-303 / PFI-703)
Maintenance Cartridge (MC -09)

*1        For the information of purchasable media, contact your local sales representative.
*2        Maximum printable length varies according to the OS and application.
