The Ricoh fi-8150U is a USB desktop document scanner designed for efficient everyday scanning. It scans up to 50 ppm / 100 ipm in duplex at 200/300 dpi in A4 portrait, provides 600 dpi optical resolution, includes a 100-sheet ADF and supports USB 3.2 connectivity.
The fi-8150U is designed for efficient A4 document capture, combining high-speed duplex scanning, reliable feeding, a 100-sheet ADF and USB 3.2 connectivity.
Clear Image Capture combines reliable CIS hardware with advanced processing for crisp, precise images and high OCR accuracy.
Load up to 100 sheets for high-volume multi-page document scanning (A4/A4 at 80 g/m²).
Automatic Separation Control, Stapled Documents Detection and enhanced paper ejection help maintain reliable feeding during high-volume scanning.
Click any image for a larger view. Official Ricoh fi-8150U product information is referenced.
The key numbers highlight the fi-8150U USB desktop scanner at a glance.
A practical choice for departments, service bureaus and business users who need fast USB scanning, flexible feeding and reliable document handling.
Digitise large batches of A4 forms, records and business documents at high speed.
Scan receipts, forms, invoices and office documents efficiently with the 100-sheet ADF.
Support departmental scanning workflows with high-volume feeding, USB connectivity and advanced PaperStream software.
| Feature | Ricoh fi-8150U | Typical Office Scanner | Manual Filing |
|---|---|---|---|
| Scan Speed | 50 ppm / 100 ipm | Lower / varies | N/A |
| Document Handling | ADF | Usually ADF only | Manual |
| ADF Capacity | 100 sheets | Varies | N/A |
| Connectivity | USB 3.2 Gen1x1 / USB 2.0 / USB 1.1 | Model dependent | N/A |
| Image Monitoring Technology | Stapled Documents Detection, Lag Detection and Automatic Separation Control | Basic / varies | N/A |
The Ricoh fi-8150U is a compact duplex USB desktop scanner combining a 100-sheet ADF with Manual Feed and flexible document handling for business workflows.
| Specification Parameter | Technical Details |
|---|---|
| Scanner Type | ADF (Automatic Document Feeder) / Manual Feed, Duplex |
| Scanning Color Mode | Color, Grayscale, Monochrome |
| Scanning Speed | 50 ppm / 100 ipm (A4 portrait, 200/300 dpi) |
| Image Sensor Type | CIS × 2 (front × 1, back × 1) |
| Light Source | RGB LED × 2 (front × 1, back × 1) |
| Optical Resolution | 600 dpi |
| Normal Document Size | Minimum 48 × 50 mm; maximum 215.9 × 355.6 mm (8.5 × 14 in.) |
| Manual Feed | Manual Feed Mode supports documents up to 7 mm thick, including IDs and pamphlets |
| Long Paper Scanning | Up to 6,096 mm (240 in.) |
| Document Handling | Paper: 20–465 g/m²; booklet: less than 7 mm; plastic card: 1.4 mm or less |
| ADF Capacity | 100 sheets (A4 80 g/m² or Letter 20 lb) |
| Interface | USB 3.2 Gen1x1 / USB 2.0 / USB 1.1 |
| Power Requirements | AC 100–240 V, 50/60 Hz |
| Power Consumption | 21 W or less operating; 17 W Eco mode; 2.0 W or less LAN sleep / 1.4 W or less USB sleep; 0.2 W or less auto standby |
| Dimensions | 300 × 170 × 163 mm |
| Weight | 4 kg (8.8 lb) |
| Multifeed Detection | Overlap detection using ultrasonic sensor and length detection |
| Driver | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS™), WIA Driver, Image Scanner Driver for macOS (ICA), Image Scanner Driver for Linux (SANE), PaperStream Capture, PaperStream ClickScan, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap™, Scanner Central Admin Server |
Official fi-8150U accessories and consumables include rollers, carrier sheets and the optional rear-side post imprinter.
Part Number: PA03810-0001
Recommended replacement cycle: up to 200,000 sheets or one year.
Part Number: PA03670-0002
Recommended replacement cycle: up to 200,000 sheets or one year.
Part Number: PA03360-0013
Pack of 5 carrier sheets.
Part Number: PA03770-0015
Pack of 3 photo carrier sheets.
Part Number: PA03810-0020
Pack of 1 booklet carrier sheet.
Part Number: PA03810-D201
Optional rear-side printing after scanning.
Will be updated soon
Will be updated soon
The Ricoh fi-8150U is a flagship desktop scanner with a 100-sheet ADF, dedicated manual feeder and USB connectivity for flexible document capture.
Users across Malaysia can choose the Ricoh fi-8150U for its compact footprint, simple front-panel operation, 50 ppm / 100 ipm duplex performance and USB connectivity.
Delivers high-speed performance of up to 50 ppm / 100 ipm duplex in A4 portrait at 200/300 dpi.
Features Ricoh Clear Image Capture, Automatic Separation Control and Paper Protection technologies.
Measures 300 × 170 × 163 mm and weighs approximately 4 kg.
Includes an ADF capacity of up to 100 sheets.
Manual Feed supports booklets less than 7 mm thick and plastic cards up to 1.4 mm, with flexible handling for special documents.
Includes PaperStream IP and PaperStream Capture for image processing and batch capture workflows.
Fast duplex scanning up to 50 ppm / 100 ipm in A4 portrait at 200/300 dpi.
Manual Feed supports booklets less than 7 mm thick and plastic cards up to 1.4 mm, with flexible handling for special documents.
Stapled Documents Detection stops feeding immediately when abnormal lifting is detected, helping prevent document damage.
PaperStream Capture supports efficient batch scanning and document capture workflows.
Automatically adjusts brake roller torque based on paper slip to reduce multi-feeds and paper pick-up issues.
Stapled Documents Detection and Lag Detection help protect originals and reduce interruptions during high-volume scanning.
Benchmark specifications and performance comparison details.
| Feature | Ricoh fi-8150U | Generic Scanner | Manual Filing |
|---|---|---|---|
| Scan Speed | 50 ppm / 100 ipm; Manual Feeder for special documents | Slow | N/A |
| Scanning Type | ADF / Manual Feeder, Duplex; 50 ppm / 100 ipm | Contact / ADF | N/A |
| Connectivity | USB 3.2 Gen1x1 / USB 2.0 / USB 1.1 | USB Only | N/A |
| Technology | Color CIS x 2 | Standard CIS / CCD | None |
| Malaysia Supplier Support | Yes ✔ | Limited | No |
Suitable for departments and workgroup scanning environments and business document processing.
Ideal for organisations requiring reliable high-volume A4 document digitisation.
Suitable for service bureaus, BPOs and departments requiring office-level scanning.
Looking for a quotation for the Ricoh fi-8150U USB desktop document scanner from Scanext Sdn. Bhd.? Contact us for official quotations, single-unit purchases and business orders across Malaysia.
Scanext Sdn. Bhd. Sdn Bhd.
Malaysia Nationwide Support.
Ask about Ricoh fi-8150U availability, quotation and Malaysia support.
