Reliable Monochrome Multifunction Printer
Pantum BM320ADN (26PPM)
Pantum BM320ADN Mono Multifunction Laser Printer
Upgrade your office workflow with the Pantum BM320ADN 3-in-1 laser printer. Combining rapid monochrome printing, automatic duplexing, and seamless network connectivity into a compact, cost-efficient package designed for modern business operations.
1. High-Performance A3 Technical Specifications
| Hardware Specification | Pantum BM320ADN Specification Details |
|---|---|
| Primary Functions | Print, Copy, Scan (3-in-1 Heavy-Duty A3 Laser MFP) |
| Print & Copy Speed | A4: Up to 26 ppm | A3: Up to 15 ppm |
| Maximum Paper Format | Native A3 Support (Supports A3, A4, A5, Letter, Executive) |
| Scanning Mechanism | Flatbed + 100-Sheet RADF (Reversing Automatic Document Feeder) |
| Duplex Capabilities | Automatic Double-Sided Printing & RADF Automated Duplex Scanning |
| Processor & Memory | High-Performance 833MHz Core | 1GB DDR4 System Memory |
| Network & Connectivity | Gigabit Ethernet (10/100/1000Base-Tx) & High-Speed USB 2.0 |
| Paper Input Capacity | 250-Sheet Cassette + 100-Sheet Multipurpose Tray (Expandable to 1,450 sheets) |
| Monthly Duty Cycle | Maximum 60,000 Pages / Month (Recommended: 4,000 Pages) |
| Consumable System | Separate High-Yield Toner (TL-3200H: 12,000 pgs) & Long-Life Drum (DL-3200: 80,000 pgs) |
2. Solving Common Corporate & SME Printing Pain Points
High Cost of A3 Outsourcing & Printing
Outsourcing large-format engineering plans, accounting ledgers, and architectural diagrams to print shops drains company operating budgets.
BM320ADN SolutionIn-house A3 laser capability with high-yield separate toner cartridges lowers cost-per-page to a fraction of outsourced printing rates.
Manual Duplex Scanning Bottlenecks
Employees spend hours manually flipping double-sided documents on flatbed scanners, causing office workflow delays.
BM320ADN SolutionIntegrated 100-sheet RADF feeder automatically flips and scans double-sided document batches with zero manual intervention.
3. Key Operational Advantages & Financial Benefits
DDR4 1GB Memory Buffer
Prevents network print buffer lag when multiple users send complex A3 CAD files or graphics-heavy PDF documents simultaneously.
Separate Drum & Toner Architecture
Replace toner cartridges (TL-3200H) without discarding the long-life 80,000-page drum unit (DL-3200), maximizing investment return.
Heavy-Duty Metal Chassis
Built with an internal steel frame engineered to maintain structural stability across a 60,000-page maximum monthly duty cycle.
4. Practical Applications & Enterprise Office Solutions
📐 Construction, Engineering & Design
Print A3 floor plans, site layouts, and mechanical schematics directly from AutoCAD or PDF with 1200 DPI razor-sharp accuracy.
📊 Accounting, Legal & Administration
Easily digitize two-sided financial audits, legal contracts, and multi-page tax ledgers using the automated RADF scanner destination presets.
5. Why Choose Scanext Sdn Bhd as Your Authorized Pantum Partner
Physical Showroom in Petaling Jaya
Test and experience the Pantum BM320ADN live before purchase at our Ara Damansara showroom.
Technical Support & Warranty Backup
Our dedicated technical team provides installation support, troubleshooting, and original consumable replacements.
Fast Delivery & On-Site Setup
Enjoy prompt local delivery and network setup services across Klang Valley, Selangor, and Kuala Lumpur.
6. Pantum BM320ADN Feature Highlights & Scalability
Pantum Utility Series Feature Highlights:
- Confidential & Security Printing: Protect sensitive corporate accounts with encrypted print release functions.
- Scan to USB Direct Drive: Insert standard USB drives into the front panel port to scan files without opening a PC.
- Versatile Media Handling: Standard 100-sheet multipurpose tray supports paper weights from 60 to 216g/m².
- Scalable Paper Trays: Optional 550-sheet extension feeder trays allow expanding total capacity up to 1,450 sheets.
7. Frequently Asked Questions (FAQ)
Does the Pantum BM320ADN support A3 size printing and copying?
Yes! The Pantum BM320ADN natively supports up to A3 large-format printing, copying, and scanning, making it ideal for technical drawings, accounting sheets, and marketing booklets.
What is the difference between Pantum BM230ADN and BM320ADN?
The Pantum BM320ADN is an A3 large-format MFP designed for higher monthly duty cycles (up to 60,000 pages) with an RADF automated duplex scanner and 1GB DDR4 memory, whereas the BM230 series is standard A4 format.
Where can I purchase or view the Pantum BM320ADN printer in Petaling Jaya?
You can visit Scanext Sdn Bhd at N-G-42, Ground Floor, Jalan PJU 1a/1, Ara Damansara, 47301 Petaling Jaya, Selangor, or WhatsApp us directly at 011-10867868 for instant stock availability.
Does the BM320ADN come with automatic double-sided printing and scanning?
Yes, it features hardware automatic duplex printing and a standard 100-page RADF (Reversing Automatic Document Feeder) for automated double-sided scanning and copying.
8. Visit Our Ara Damansara Showroom & Contact Options
Ready to Upgrade Your Office Printing Setup?
Contact Scanext Sdn Bhd today for the best local price quotes, printer rentals, or to schedule a live product demonstration at our Ara Damansara showroom.
Address: N-G-42, Ground Floor, Jalan PJU 1a/1, Ara Damansara, 47301 Petaling Jaya, Selangor.
Website: www.scanext.com.my
