Compact yet powerful. The fastest A3 scanner in its class for maximum productivity in limited workspaces.
| Capability | Ricoh fi-7480 | Standard Flatbed |
|---|---|---|
| Scan Size | Up to A3 | Usually A4 |
| Feed Method | ADF (Batch Scanning) | Manual (Single Sheet) |
| Speed | 80 ppm (High Speed) | Slow |
| Protection | iSOP & Skew Reducer | Basic protection |
The Ricoh fi-7480 is a high-performance, compact A3 production scanner designed to streamline document-heavy workflows in a space-saving footprint.
| Scanner Type | ADF (Automatic Document Feeder) / Manual Feed, Duplex Scanning |
|---|---|
| Scanning Speed (A4 Landscape) (Color / Grayscale / Monochrome) | Simplex: 80 ppm (200/300 dpi) Duplex: 160 ipm (200/300 dpi) |
| Scanning Speed (A4 Portrait) (Color / Grayscale / Monochrome) | Simplex: 60 ppm (200/300 dpi) Duplex: 120 ipm (200/300 dpi) |
| Image Sensor Type | Color CCD x 2 (Front x 1, Back x 1) |
| Light Source | White LED Array x 4 (Front x 2, Back x 2) |
| Optical Resolution | 600 dpi |
| Output Resolution | 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (via driver interpolation) |
| Output Format | Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Background Colors | White / Black (Selectable) |
| Expected Daily Volume | 44,000 sheets |
| ADF Chute Capacity | 100 sheets (A4 80 g/m² or Letter 20 lb) |
|---|---|
| Maximum Document Size | 304.8 x 431.8 mm (12 x 17 in.) (A3 size) |
| Minimum Document Size | 50.8 x 69 mm (2 x 2.7 in.) (A8 size) |
| Long Paper Scanning | Up to 5,588 mm (220 in.) |
| Paper Weight (Thickness) | 27 to 413 g/m² (7.2 to 110 lb) *Supports thicknesses up to 128 to 209 g/m² for A8 size |
| Plastic Card Support | Up to 1.4 mm or less (Supports ISO7810 compliant cards, embossed type supported) |
| Envelopes & Mixed Batches | Supported via manual feeding mode and independent side guide controls |
| Interface Connectivity | USB 3.0 / USB 2.0 / USB 1.1 (Type-B) |
|---|---|
| Multifeed Detection | Overlap detection (Ultrasonic sensor), Length detection |
| Paper Protection Technology | Lag Detection, Sound Detection (iSOP - Intelligent Sonic Paper Protection) |
| Advanced Feeding Controls | Skew Reducer mechanism, Independent Pick Rollers |
| Control Panel | Operational LCD panel with status display and navigation buttons |
| Power Requirements | AC 100 V to 240 V, 50/60 Hz |
|---|---|
| Power Consumption | Operating Mode: 43 W or less Sleep Mode: 1.4 W or less Auto Standby (Off) Mode: 0.3 W or less |
| Operating Environment | Temperature: 5°C to 35°C (41°F to 95°F) Relative Humidity: 20% to 80% (Non-condensing) |
| Environmental Compliance | ENERGY STAR®, RoHS |
| Dimensions (W x D x H) | 380 x 209 x 168 mm (15.0 x 8.2 x 6.6 in.) |
| Weight | 7.6 kg (16.8 lb) |
| Supported Operating Systems | Windows® 11, Windows® 10, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, macOS, Linux |
|---|---|
| Bundled Software & Drivers | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), PaperStream Capture, PaperStream ClickScan, Software Operation Panel, Error Recovery Guide, Scanner Central Admin, 2D Barcode for PaperStream |
| Advanced Image Functions | Multi-image output, Auto color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), Edge filler, De-Skew, Hole punch removal, Index tab cropping, Split image, Vertical streaks reduction |
Lihat kecekapan Ricoh fi-7480 dalam mengendalikan tugasan digitalisasi anda.
Video Placeholder for fi-7480 Demonstration
Muat turun brosur rasmi untuk spesifikasi penuh atau hubungi pasukan pakar kami melalui WhatsApp untuk pertanyaan lanjut atau sebut harga.
Download PDF Datasheet WhatsApp Us Now
