Print Head: PF-03
Technology: FINE (Photolithography Inkjet Nozzle Engineering)
Print Resolution (Max.) : 2400 x 1200dpi
Number of Nozzles : 2,560 Nozzles per Colour (30,720 Total)
Droplet Size :  4 Picoliter
Nozzle Pitch (Head Resolution) :1200dpi x 2
Print Head Swath : 1.07in.
Ink Tank
Ink Type : LUCIA (pigment-based)
Model : PFI-301 / 701 (C, M, Y, PC, PM, MBK, BK, GY)
Ink Capacity : 330ml / 700ml each (bundled starter ink: 330ml)
Number of Colours:8
Ink Supply Method: Tubing system (with sub-tank)
Nozzle Recovery System : Non-firing Nozzle Detection and Compensation
Printer Controller : L-COA Controller
Printer Memory : 384MB
Media feed:Front-loading Manual Feed, Front-loading Roll Feed
Hard Disk : 80GB
Media Width
Roll Feed : 254mm - 1118mm
Cut Sheet : 203mm - 1118mm
Media size
Cutsheet : ISO A4, A3, A3+, A2, A2+, A1, A0, B4, B3, B2, B1, B0, DIN C4, C3, C2, C1, C0, JIS B4, B3, B2, B1, B0, ANSI Letter (8.5" x 11"), Legal (8.5" x 14"), 11" x 17", 13" x 19", 17" x 22", 22" x 34", 28" x 40", 34" x 44", ARCH (9" x 12",12" x 18", 18" x 24", 24" x 36", 26" x 38", 27" x 39", 30" x 42", 36" x 48"), 20" x 24", 18" x 22", 14" x 17", 12" x 16", 10" x 12", 10" x 15", 8" x 10", 16" x 20" (US Photo size), Poster (20" x 30", 30" x 40", 42" x 60", 44" x 62", 300 x 900mm), 13" x 22"
Roll paper: IS0 A3, A2, A1, A0, JIS B2, B1, B0, ARCH D (24", 30", 36"), 10", 14", 16", 17", 42", 44"
Media Type*1 : Plain Paper, Plain paper (High Quality), Coated paper, Heavyweight coated paper, Premium matte paper, Glossy photo paper, Semi-glossy photo paper, Backlit film, Backprint film, Flame-Resistant cloth, Fine art photo, Fine art heavyweight photo, Fine art textured, Canvas matte
Printable Margins
Roll Feed All Sides:    5mm or 0mm for Borderless
Cutsheet Left, Right, Top: 5mm
Bottom: 23mm
Minimum Printable Media length : 8.0" (203mm)
Maximum Print length*2
Roll Feed : 59" (18m)
Cut Sheet: 5.2" (1.6m)
Borderless Printing Widths (Roll Media Only): JIS B2 (515mm), JIS B0 (1030mm), ISO A1 (594mm), ISO A0 (841mm), 10", 14", 16", 24", 36", 42"
Media Cutter : Automatic horizontal cutting (Rotary cutter)
Media Thickness : 0.07 - 0.8mm
Media Core Sizes : Internal diameter of roll core:      2" / 3"(Option)
Maximum Roll Outer Diameter : 150mm or less
Software
Printing Software : imagePROGRAF Printer Driver 2007, Print Plug-in for Photoshop, Print Plug-in for DPP, Printer Driver Extra Kit (Free Layout, imageRUNNER Linking Function)
Utilities : Media Configuration Tool, GARO Status Monitor (Windows) /
Print Monitor (MAC), Remote UI
Applications:   Digital Photo Front-Access, Poster Artist 2007 (optional)
Printer language: GARO (Canon Proprietary)
Operating Systems : Windows (2000, XP, Windows Vista 32 / 64 bit),Macintosh (OS9 / X)
Interface
Standard (Built-in) : USB 2.0 Hi-Speed, 10 / 100Base-T / TX
Optional : IEEE1394 (FireWire)
Acoustic noise
Operation : 50dB (A) or Less
Standby : 35dB (A) or Less
Acoustic Power : 6.6 Bels or Less
Power Supply : AC 100 - 240V (50 - 60Hz)
Power Consumption
Maximum : 190W or Less
Standby : (100 - 120V) 5W or Less (10W or less when IEEE1394 is mounted)
Standby : (220 - 240V) 6W or Less (10W or less when IEEE1394 is mounted)
Power Off : 1W or Less (Executive Order Compliant)
Certifications : UL, FCC Class B, PSB, CCC, ENERGY STAR (WW), RoHS directive
Operational Environment
Temperature:   15 - 30°C
Relative Humidity : 10 - 80% (No Condensation)
Dimensions (H x W x D) : 1893 x 975 x 1144mm (with Printer Stand & Basket)
Weight (with Stand) : Approx. 140kg
User Replaceable Items : Print Head (PF-03)
Ink Tanks (PFI-301): 330ml; (PFI-701): 700ml
Cutter Blade (CT-06)
Maintenance Cartridge (MC -08)

*1 For the information of purchasable media, contact your local sales representative.
*2 Maximum printable length varies according to the OS and application.
