A1 A0 Laser Printer Black & White Copy, Color Scan

RICOH MPW8140SP

Large Format Laser Printer Multifunction 3 in 1

Overview
Ricoh MPW8140SP has been specially created for the needs of CAD and PFP to increase the speed of high quality output and lower the cost. Its compact design combines the reliability, durability and ease of use that are so essential in today’s workplace. All of which helps drives business and profits.

MAIN FEATURE

New and even better wide format printing.
High-speed monochrome printing at 14 pages/minute (A1 Horizontal).
Colour Scanner.
New USB/SD slot.
Space saving in design and operation

GENERAL

Technology:
Fusing:
Toner Type:
Print Speed:
Copy Speed:
Print Resolution:

Copy Resolution:
Warm-up time:
Dimensions (WxDxH):
Weight:
Power Source:
Power Consumption:

Electro-photographic printing
Heat and pressure
Magnetic brush dual component dry toner system
MP W8140SP: 7ppm @A0/E SEF, 14ppm @A1/D LEF
MP W8140SP: 170mm/sec 14cpm/ppm @ A1/D LEF
RPCS 600dpi PS3/PDF 600/300dpi
RP-GL/GL2 600dpi/400dpi
RTIFF 600/400/300/200dpi
600dpi
Less than 120 sec.
1,250 x 755 x 1,215mm
Less than 295kg
220V-240V/8A 50/60Hz
Printing: less than 3kW

SCANNER FEATURE

Colour Scanner Resolution:
Scan Speed:
Scan Area:

150/200*/300/400/600 *Default Twain 150-1200dpi
BW 42.5-340mm/s
MP W8140SP: (Metric) 914.4mm x 30,000mm
Min: 210mm x 210mm

MEDIA HANDLING

Paper Input Capacity:

Original width:
Maximum width:
Paper Size:

Paper Weight:

SEF: A0/A1/A2/A3/A4
LEF: A1/A2/A3/A4
210-914.4mm
914mm
Maximum: 914 x 150,00mm
2 roll papers Width : 210mm - 914mm
Max length: 15,000mm
Roll Paper: 51-134g/m2

PRINT CONTROLLER SPECIFICATION

Configuration:
CPU:
Memory:
HDD:
Operating System:

Network Protocol:
Supported Print Language:
Font:
Network Interface:
Service Interface:

Embedded (Copier-Printer-Scanner)
Calpella (1.06 GHz)
2.5GB
320GB(Shared with Copy/Printer/Scanner applications)
Windows: XP/Vista/7/8/8.1/2003server/2008server/2008R2server/2012server/2012serverR2
Mac: OS (later than Mac OS8.6) Mac: OS X (later than Mac OS X10.7)
Citrix Presentation: Server 4.5
TCP/IP(IPv4, IPv6), IPX/SPX, Auto switching available
PostScript Level3(PDF), RPCS, Emulation: HP-GL, HP-GL/2(HP-RTL), TIFF(CALS)
European 136 fonts
Standard: 100/10base-TX, USB2.0 Option: IEEE802.11a/g/n (wireless)
2 slots USB 2.0 host

Other Option
