Warm-Up Time

​Basic: 11.0 seconds/ SP: 14.0 seconds

First Output Speed

​4.0/2.9/2.9 seconds

Continuous Output Speed

​40/50/60 pages per minute

Memory

​2GB (Maximum)

HDD

320GB (Basic: Optional)

Dimension (W x D x H)

​With ARDF: 587 x 680 x 913 mm
With SPDF: 587 x 680 x 963 mm

Weight

With ARDF: 68.5 kg
With SPDF: 74 kg

Power Source

​220 - 240 V, 50/60 Hz

Copying Process

​Twin laser beam scanning & electro photographic
printing

Multiple Copying

Up to 999 copies

Resolution

600 dpi

Zoom

​From 25% to 400% in 1% step

Printer Language

Standard : PCL5e, PCL6, Adobe® PDF Direct
Option : Adobe® PostScript® 3™, IPDS, XPS

Print Resolution

​600 x 600 dpi, 1,200 x 1,200 dpi (Maximum)

Interface

Standard : USB 2.0 Type A, USB 2.0 Type B, SD slot, Ethernet 10 base-T/100 base-TX, Ethernet 1000 Base-T
Option : Bi-directional IEEE 1284/ECP, *Wireless, LAN (IEEE 802.11a/b/g/n), *Bluetooth, *Additional NIC (2nd port)

Network Protocol

​TCP/IP (IP v4, IP v6), IPX/SPX (Option)

Windows Environments

Windows® XP, Windows® Vista, Windows®7,
Windows® 8, Windows® 8.1, Windows® Server 2003,
Windows® Server 2008, Windows® Server 2008R2,
Windows® Server 2012, Windows® Server 2012R2

Ma c OS Environments

​Macintosh OS X v10.6 or later

UNIX Environments

UNIX Sun® Solaris: 9, 10
HP-UX: 11.x, 11i v2, 11i v3
SCO OpenServer: 5.0.7, 6.0
RedHat® Linux Enterprise: v4, v5, v6
IBM® AIX: v5L, v5.3, v6.1, v7.1

​Novell® Netware®
environments

​v6.5

​SAP® R/3® environments

​SAP® R/3®

Scanning Speed

ARDF: Max. 80 originals per minute

Resolution

​600 dpi, 1200 dpi (TWAIN)

File Format

​TIFF, JPEG, PDF, Encryption PDF, High Compression PDF, PDF-A

Bundled Drivers

​Network TWAIN

Scan To

​E-mail, Folder, USB/SD, URL NCP (Optional)

Circuit

PSTN, PBX

Compatibility

​ITU-T (CCITT) G3

Resolution

​8 x 3.85 line/mm, 200 x 100 dpi
8 x 7.7 line/mm, 200 x 200 dpi
8 x 15.4 line/mm, 16x 15.4 line/mm
400 x 400 dpi (Optional)

Transmission Speed

G3: Approx. 3 second(s) (200 x 100 dpi, JBIG)
Approx. 2 second(s) (200 x 100 dpi)

Modem Speed

Maximum: 33.6 Kbps

Memory Capacity

​Standard: 4 MB
Maximum: 60 MB

Recommended Paper Size

A3, A4, A5, A6, B4, B5, B6

Paper Input Capacity

​Standard: 1,150 sheets
Maximum: 4,700 sheets

Paper Output Capacity

​Standard: 500 sheets
Maximum: 3,625 sheets

Paper Weight

​Standard paper tray(s): 60 - 300 g/m²
Bypass tray: 52 - 300 g/m²
Duplex unit: 52 - 256 g/m²

Power Consumption

​Maximum: 1,780 W
Ready mode: 81.4 W
Sleep mode: 0.48 W (Basic)/ 0.51 W (SP)
TEC (Typical Electricity Consumption):
Basic: 1,883/2,715/3,324 W/h
SP: 1,607/2,253/2,719 W/h

Software

​GlobalScan NX, Device Manager NX, Enhanced Locked Printed NX,
Streamline NX, Card Authentication Package, Unicode Font Package for SAP
