Ricoh fi-8930
A flagship production scanner engineered for massive-scale digitization. Experience unmatched speed, industrial durability, and professional-grade intelligence.
Extreme Throughput
Blazing speeds of up to 130 ppm / 260 ipm. Engineered for high-volume, continuous production environments.
Intelligent Tech
Features an Automatic Image Quality Checker to ensure perfect scans without the need for manual re-processing.
Industrial Build
A 500-sheet ADF designed to process tens of thousands of pages daily with elite-level mechanical stability.
Performance Technicals
| Feature | Technical Specification |
|---|---|
| Scan Speed (A4) | 130 ppm / 260 ipm |
| ADF Capacity | 500 sheets |
| Daily Duty Cycle | 100,000 sheets/day |
| Connectivity | USB 3.2 Gen 1x1 / 1000BASE-T |
| Sensor Type | CIS x 4 (Front & Back) |
| Quality Check | Automatic Image Quality Checker |
Key Advantages
- Automatic Image Quality Checker: Real-time detection of folded corners or multi-feeds to minimize data loss.
- Flexible Media Handling:
Ricoh fi-8930 Production Scanner
The fi-8930 is a high-capacity production scanner engineered for centralized, high-volume digitization projects. With industry-leading paper-handling technologies and exceptional image quality, it streamlines complex document workflows.
- High-Speed Performance: Up to 130 ppm / 260 ipm (A4 landscape).
- Large Capacity: 750-sheet Automatic Document Feeder (ADF).
- Clear Image Capture: Proprietary technology for high-definition data extraction.
- Reliability: 110,000 sheets daily duty cycle.
- Advanced Connectivity: USB 3.2 Gen 1 and Gigabit Ethernet.
Technical Specifications
1. Scanning Performance & Optics
| Scanner Type | ADF (Automatic Document Feeder) / Manual Feed, Duplex Scanning |
|---|---|
| Scanning Speed (A4 Landscape) (Color / Grayscale / Monochrome) | Simplex: 130 ppm (200/300 dpi) Duplex: 260 ipm (200/300 dpi) |
| Scanning Speed (A4 Portrait) (Color / Grayscale / Monochrome) | Simplex: 100 ppm (200/300 dpi) Duplex: 200 ipm (200/300 dpi) |
| Image Sensor Type | CIS x 2 (Front x 1, Back x 1) with PFU Clear Image Capture |
| Light Source | RGB LED x 4 (Front x 2, Back x 2) |
| Optical Resolution | 600 dpi |
| Output Resolution | 50 to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (via driver interpolation) |
| Output Format | Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Background Colors | White / Black (Selectable) |
| Expected Daily Volume | 110,000 sheets / day |
2. Document & Media Handling
| ADF Chute Capacity | 750 sheets (A4 80 g/m² or Letter 20 lb, total thickness < 80 mm) 500 sheets (A3 80 g/m², total thickness < 53 mm) |
|---|---|
| Maximum Document Size | 304.8 x 431.8 mm (12 x 17 in.) (A3 size) |
| Minimum Document Size | 48 x 70 mm (1.9 x 2.8 in.) |
| Long Paper Scanning | Up to 6,096 mm (240 in.) at 200 dpi / 5,461 mm at 300 dpi |
| Paper Weight (Straight Scan) | Larger than A5 to A4: 20 to 570 g/m² (5.3 to 152 lb) A5 or smaller & Over A4: 40 to 570 g/m² (11 to 152 lb) |
| Paper Weight (U-turn Scan) | Larger than A5 to A4: 20 to 209 g/m² A5 or smaller: 64 to 209 g/m² Over A4: 64 to 256 g/m² |
| Envelope Support | Thickness 1.25 mm (0.05 in.) or less (via Straight Scan path) |
3. Feeding Intelligence & Connectivity
| Interface Connectivity | USB 3.2 Gen1 / USB 3.0 / USB 2.0 / USB 1.1 Ethernet: 10BASE-T, 100BASE-TX, 1000BASE-T |
|---|---|
| Multifeed Detection | Overlap detection (Ultrasonic sensor x 3: Left, Centre, Right), Length detection |
| Paper Protection Technology | Stapled Documents Detection (All-location protection), Lag detection |
| Advanced Feeding Control | Automatic Skew Correction (Individual page alignment), Automatic Separation Control, Advanced Paper Ejection Control |
| Control Panel | 4.3-inch Color Touchscreen and navigation buttons |
| Maintenance Features | 105° Wide opening angle, Internal LED lights for easy servicing |
4. Power, Physical & Environmental Data
| Power Requirements | AC 100 V to 240 V ±10%, 50/60 Hz |
|---|---|
| Power Consumption | Operating Mode: 70 W or less (40 W or less in Eco mode) Sleep Mode: 2.5 W or less Auto Standby (Off) Mode: 0.2 W or less |
| Operating Environment | Temperature: 5°C to 35°C (41°F to 95°F) Relative Humidity: 15% to 80% (Non-condensing) |
| Environmental Compliance | ENERGY STAR®, RoHS, EPEAT® Gold rated |
| Dimensions (W x D x H) | 460 x 430 x 315 mm (18.1 x 16.9 x 12.4 in.) |
| Weight | 23 kg (50.7 lb) |
5. Software Suite & Image Optimization
| Supported Operating Systems | Windows® 11, Windows® 10, Windows Server® 2025, Windows Server® 2022, Windows Server® 2019, Windows Server® 2016 |
|---|---|
| Bundled Software & Drivers | PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), PaperStream Capture, PaperStream ClickScan, Software Operation Panel, Error Recovery Guide, Scanner Central Admin |
| Advanced Image Core Functions | Multi Image output, Automatic color detection, Blank page detection, Static threshold, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, Dither, De-Screen, Emphasis, Dropout color (None/Red/Green/Blue/White/Saturation/Custom), sRGB output, Hole punch removal, Cropping, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Character extraction, Background pattern removal, Automatic profile selection |
Product Video
Watch how the Ricoh fi-8930 optimizes your workflow efficiency.
[Video Showcase Placeholder]
Product Documentation
Download the official brochure to learn more about the technical capabilities of the Ricoh fi-8930.
Download Datasheet (PDF) WhatsApp Us Now
